Water Purifier - Aquaguard Aspire Designo UTC RO+UV Copper 4. Trouble Shooting

Water Purifier - Aquaguard Aspire Designo UTC RO+UV Copper 4. Trouble Shooting



🚨 Troubleshooting Guide

âť— 1. No Water Flow

🔍 Possible Causes

  • Inlet tap is closed

  • Low water pressure

  • Pre‑filter clogged

  • RO membrane choked

âś… Solutions

  • Ensure inlet tap is fully open

  • Check if building water supply is available

  • Clean/replace pre‑filter

  • Contact service for membrane check

âť— 2. Slow Water Flow

🔍 Possible Causes

  • Sediment filter blocked

  • Carbon filter saturated

  • Low pressure from source

âś… Solutions

  • Replace sediment filter

  • Replace carbon filter

  • Ensure Zero Pressure Pump is ON

âť— 3. Water Tastes Unusual

🔍 Possible Causes

  • Carbon filter exhausted

  • Copper infusion too high

  • Tank not cleaned

âś… Solutions

  • Replace carbon filter

  • Flush 5–7 litres

  • Clean storage tank

âť— 4. Tank Not Filling

🔍 Possible Causes

  • RO membrane blocked

  • Pump not running

  • Float valve stuck

âś… Solutions

  • Replace RO membrane

  • Check power supply

  • Reset float valve

âť— 5. LED Indicators Not Working

🔍 Possible Causes

  • Loose wiring

  • LED PCB fault

âś… Solutions

  • Restart purifier

  • Contact service technician

âť— 6. Copper Taste Too Strong

🔍 Possible Causes

  • Copper module over‑infusion

âś… Solutions

  • Flush 10 litres

  • If persists, request module calibration
